Self-healing film Power capacitor bank for rail traction
Technical data
| Operating temperature range | Max.Operating temperature.,Top,max: + 70℃Upper category temperature: +60℃Lower category temperature: -40℃ | |
| capacitance range |
100μF～20000μF |
|
| Un/ Rated voltage Un |
600V.DC～4000V.DC |
|
| Cap.tol |
±5%(J) ;±10%(K) |
|
| Withstand voltage |
Vt-t |
1.5Un DC/60S |
|
Vt-c |
1000+2×Un/√2 （V.AC） 60S(min 3000 V.AC) |
|
| Over Voltage |
1.1Un(30% of on-load-dur.) |
|
|
1.15Un(30min/day) |
||
|
1.2Un(5min/day) |
||
|
1.3Un(1min/day) |
||
|
1.5Un(100ms every time,1000times during the lifetime) |
||
| Dissipation factor |
tgδ≤0.003 f=100Hz |
|
|
tgδ0≤0.0002 |
||
| ESL |
＜150 nH |
|
| Flame retardation |
UL94V-0 |
|
| Maximum aititude |
2000m |
|
| When the altitude is above 2000m to below 5000m, it is necessary to consider the use of reduced amount.(for each increase of 1000m, the voltage and current will be reduced by 10%)
|
||
| Life expectancy |
100000h(Un; Θhotspot ≤70 °C ) |
|
| Reference standard |
IEC 61071 ;IEC 61881; |
|
Feature
1. Metal shell encapsulation, dry resin infusion;
2. Copper nut / screw leads, easy installation;
3. Large capacity, small size;
4. Resistance to high voltage, with self-healing;
5. High ripple current, high dv / dt withstand capability.
Like other CRE products , the series capacitor have UL certificate and 100% burn-in tested.
Application
1. Railway traction;
2. Pv inverter;
3. wind power converter;
4. All kinds of frequency converter and inverter power supply;
5. Pure electric and hybrid cars;
6. SVG, SVC devices
7. other kinds of power quality management.
Typical circuit
Life expectancy
Outline drawing
| Voltage | Un 800V.DC Us 1200V Ur 200V | ||||||||
| Cn (μF) | W (mm) | T (mm) | H (mm) | dv/dt (V/μS) | Ip (KA) | Irms(A)50℃@10KHz | ESR (mΩ) @1KHz | Rth (K/W) | Weight （Kg） |
| 4000 | 340 | 125 | 190 | 5 | 20.0 | 120 | 1.1 | 0.9 | 17.6 |
| 8000 | 340 | 125 | 350 | 4 | 32.0 | 180 | 0.72 | 0.6 | 31.2 |
| 6000 | 420 | 125 | 245 | 5 | 30.0 | 150 | 0.95 | 0.7 | 26.4 |
| 10000 | 420 | 125 | 360 | 4 | 40.0 | 200 | 0.72 | 0.5 | 39.2 |
| 12000 | 420 | 235 | 245 | 4 | 48.0 | 250 | 0.9 | 0.3 | 49.6 |
| 20000 | 420 | 235 | 360 | 3 | 60.0 | 300 | 0.6 | 0.3 | 73.6 |
| Voltage | Un 1200V.DC Us 1800V Ur 300V | ||||||||
| Cn (μF) | W (mm) | T (mm) | H (mm) | dv/dt (V/μS) | Ip (KA) | Irms(A)50℃@10KHz | ESR (mΩ) @1KHz | Rth (K/W) | Weight （Kg） |
| 2500 | 340 | 125 | 190 | 8 | 20.0 | 120 | 1.1 | 0.9 | 17.6 |
| 3300 | 340 | 125 | 245 | 8 | 26.4 | 150 | 0.95 | 0.7 | 22.4 |
| 5000 | 420 | 125 | 300 | 7 | 35.0 | 180 | 0.8 | 0.6 | 32.8 |
| 7500 | 420 | 125 | 430 | 5.5 | 41.3 | 200 | 0.66 | 0.6 | 44.8 |
| 5000 | 340 | 235 | 190 | 8 | 40.0 | 200 | 1.1 | 0.3 | 32.8 |
| 10000 | 340 | 235 | 350 | 6 | 60.0 | 250 | 0.8 | 0.3 | 58.4 |
| 5000 | 420 | 235 | 175 | 8 | 40.0 | 200 | 1 | 0.4 | 36 |
| 7500 | 420 | 235 | 245 | 7 | 52.5 | 250 | 0.9 | 0.3 | 49.6 |
| 10000 | 420 | 235 | 300 | 7 | 70.0 | 250 | 0.8 | 0.3 | 61.6 |
| 15000 | 420 | 235 | 430 | 5 | 75.0 | 300 | 0.6 | 0.3 | 84 |
| Voltage | Un 1500V.DC Us 2250V Ur 450V | ||||||||
| Cn (μF) | W (mm) | T (mm) | H (mm) | dv/dt (V/μS) | Ip (KA) | Irms(A)50℃@10KHz | ESR (mΩ) @1KHz | Rth (K/W) | Weight （Kg） |
| 1200 | 340 | 125 | 190 | 10 | 12.0 | 120 | 1.1 | 0.9 | 17.6 |
| 3000 | 340 | 125 | 420 | 8 | 24.0 | 180 | 0.66 | 0.7 | 37.6 |
| 2000 | 420 | 125 | 245 | 10 | 20.0 | 150 | 0.95 | 0.7 | 26.4 |
| 4000 | 420 | 125 | 430 | 8 | 32.0 | 200 | 0.66 | 0.6 | 44.8 |
| 5000 | 340 | 235 | 350 | 8 | 40.0 | 250 | 0.8 | 0.3 | 58.4 |
| 4000 | 420 | 235 | 245 | 10 | 40.0 | 250 | 0.9 | 0.3 | 49.6 |
| 8000 | 420 | 235 | 430 | 8 | 64.0 | 300 | 0.6 | 0.3 | 84 |
| Voltage | Un 2000V.DC Us 3000V Ur 600V | ||||||||
| Cn (μF) | W (mm) | T (mm) | H (mm) | dv/dt (V/μS) | Ip (KA) | Irms(A)50℃@10KHz | ESR (mΩ) @1KHz | Rth (K/W) | Weight （Kg） |
| 1000 | 340 | 125 | 245 | 12 | 12.0 | 150 | 0.95 | 0.7 | 22.4 |
| 1500 | 340 | 125 | 350 | 10 | 15.0 | 180 | 0.72 | 0.6 | 31.2 |
| 2000 | 420 | 125 | 360 | 10 | 20.0 | 200 | 0.72 | 0.5 | 39.2 |
| 2400 | 420 | 125 | 430 | 9 | 21.6 | 200 | 0.66 | 0.6 | 44.8 |
| 3200 | 340 | 235 | 350 | 10 | 32.0 | 250 | 0.8 | 0.3 | 46.4 |
| 4000 | 420 | 235 | 360 | 10 | 40.0 | 280 | 0.7 | 0.3 | 58.4 |
| 4800 | 420 | 235 | 430 | 9 | 43.2 | 300 | 0.6 | 0.3 | 67.2 |
| Voltage | Un 2200V.DC Us 3300V Ur 600V | ||||||||
| Cn (μF) | W (mm) | T (mm) | H (mm) | dv/dt (V/μS) | Ip (KA) | Irms (A)max | ESR (mΩ) | Rth (K/W) | Weight （Kg） |
| 2000 | 420 | 235 | 245 | 12 | 24 | 150 | 0.9 | 0.740740741 | 40 |
| 2750 | 420 | 235 | 300 | 10 | 27.5 | 200 | 0.8 | 0.46875 | 49.6 |
| 3500 | 420 | 235 | 360 | 10 | 35 | 200 | 0.7 | 0.535714286 | 58.4 |
| Voltage | Un 3000V.DC Us 4500V Ur 800V | ||||||||
| Cn (μF) | W (mm) | T (mm) | H (mm) | dv/dt (V/μS) | Ip (KA) | Irms (A)max | ESR (mΩ) | Rth (K/W) | Weight （Kg） |
| 1050 | 420 | 235 | 245 | 20 | 21 | 150 | 0.9 | 0.740740741 | 40 |
| 1400 | 420 | 235 | 300 | 15 | 21 | 200 | 0.8 | 0.46875 | 49.6 |
| 1800 | 420 | 235 | 360 | 15 | 27 | 200 | 0.7 | 0.535714286 | 58.4 |
| Voltage | Un 4000V.DC Us 6000V Ur 1000V | ||||||||
| Cn (μF) | W (mm) | T (mm) | H (mm) | dv/dt (V/μS) | Ip (KA) | Irms (A)max | ESR (mΩ) | Rth (K/W) | Weight （Kg） |
| 600 | 420 | 235 | 245 | 20 | 12 | 150 | 0.9 | 0.740740741 | 40 |
| 800 | 420 | 235 | 300 | 20 | 16 | 200 | 0.8 | 0.46875 | 49.6 |
| 1000 | 420 | 235 | 360 | 20 | 20 | 200 | 0.7 | 0.535714286 | 58.4 |
| Voltage | Un 2800V.DC Us 4200V Ur 800V | ||||||||
| Cn (μF) | W (mm) | T (mm) | H (mm) | dv/dt (V/μS) | Ip (KA) | Irms(A)50℃@10KHz | ESR (mΩ) @1KHz | Rth (K/W) | Weight （Kg） |
| 2×1000 | 560 | 190 | 310 | 20 | 2×20 | 2×350 | 1 | 0.2 | 60 |
| Voltage | Un 3200V.DC Us 4800V Ur 900V | ||||||||
| Cn (μF) | W (mm) | T (mm) | H (mm) | dv/dt (V/μS) | Ip (KA) | Irms(A)50℃@10KHz | ESR (mΩ) @1KHz | Rth (K/W) | Weight （Kg） |
| 2×1200 | 340 | 175 | 950 | 15 | 2×18 | 2×200 | 1.0 | 0.5 | 95 |
