High pulse current rating resonance capacitor RMJ-PC
Technical data
|
Operating temperature range |
Max.Operating temperature.,Top,max: +105℃Upper category temperature: +85℃ Lower category temperature: -40℃ |
|
Capacitance range |
1～8μF |
|
Rated voltage |
1200V.DC～2000V.DC |
|
Cap.tol |
±5%(J) ; |
|
Withstand voltage |
1.5Un DC/60S |
|
Dissipation factor |
tgδ≤0.001 f=1KHz |
|
Insulation resistance |
RS*C≥5000S(at20℃ 100V.DC 60S) |
|
Life expectancy |
100000h(Un; Θhotspot≤85°C) |
|
Reference standard |
IEC61071;IEC 60110 |
Feature
1. ESR frequency stability
2. Temperature and voltage stability: Capacitance (and all other ratings) can change with the input voltage level and temperature.
Application
1. Widely used in power electronic devices in series / parallel resonant circuit.
2. Welding, power supplies, medical devices, induction heating equipment resonance occasions.
Outline drawing
| Voltage | Un 1200V.DC Urms 500V.AC | ||||||
| Cn (μF) | φD (mm) | H (mm) | ESL (nH)) | dv/dt (V/μS) | Ip (KA) | Irms(40℃ @100KHz | ESR 100kHz (mΩ) |
| 2 | 63 | 50 | 20 | 500 | 1.0 | 30 | 3.2 |
| 3 | 63 | 50 | 22 | 500 | 1.5 | 35 | 3 |
| 4 | 63 | 50 | 22 | 400 | 1.6 | 45 | 2.8 |
| 5 | 63 | 50 | 23 | 400 | 2.0 | 50 | 2.5 |
| 6 | 76 | 50 | 25 | 350 | 2.1 | 60 | 2 |
| 7 | 76 | 50 | 25 | 300 | 2.1 | 65 | 1.5 |
| Voltage | Un 1600V.DC Urms 600V.AC | ||||||
| Cn (μF) | φD (mm) | H (mm) | ESL (nH) | dv/dt (V/μS) | Ip (KA) | Irms (A)max | ESR (mΩ) |
| 2 | 63 | 50 | 20 | 700 | 1.4 | 30 | 3.2 |
| 3 | 63 | 50 | 22 | 600 | 1.8 | 35 | 3 |
| 4 | 63 | 50 | 22 | 550 | 2.2 | 45 | 2.8 |
| 5 | 76 | 50 | 23 | 500 | 2.5 | 55 | 2.3 |
| 6 | 76 | 50 | 25 | 450 | 2.7 | 65 | 2.2 |
| Voltage | Un 2000V.DC Urms 700V.AC | ||||||
| Cn (μF) | φD (mm) | H (mm) | ESL (nH) | dv/dt (V/μS) | Ip (KA) | Irms (A)max | ESR (mΩ) |
| 2 | 63 | 50 | 20 | 800 | 1.6 | 50 | 3 |
| 3 | 63 | 50 | 22 | 700 | 2.1 | 55 | 2.8 |
| 4 | 76 | 50 | 22 | 600 | 2.4 | 65 | 2.5 |
